HX-0106 – Hour Meter
Displays the number of hours unit has been in operation
HX-0107 – Time Delay Shutdown
Timer will shut unit off automatically when trigger gun is released and timer reaches setting (You cannot order HX-0107 and HX-0108 together, you will need to order HX-0223 instead.)
HX-0108 – (1) Remote Station (Auto Start/Stop Not Available), Plastic Control Box
Adds plastic control box with rocker switches, can be mounted away from unit to control on/off, burner and soap injection (You cannot order HX-0107 and HX-0108 together, you will need to order HX-0223 instead.)
HX-0110 – Additional Remotes (Up to 3)
Additional plastic control boxes with rocker switches, can be added to unit after the first remote is installed; requires HX-0108, HX-0124 or HX-0223 option
HX-0111 – Auto Start/Stop
When trigger gun is released, the timer will turn unit off; when trigger gun is pulled, unit will restart
HX-0112 – K7 Unloader, Flow Activated (Auto Start/Stop Not Available)
Converts pressure trapping unloader system to flow actuated K7 unloader
HX-0114 – Dual Gun
Two guns may be sprayed at the same time, flow is divided between the two guns while each operator maintains equal system pressure
HX-0115 – Stainless-Steel Access Panels
Converts powder coated painted access panels to stainless-steel material
HX-0116 – Stainless-Steel Coil Wrap
Converts powder coated painted coil wrap to stainless-steel material
HX-0117 – Painted Box Kit
Adds painted side and end panels
HX-0118 – Painted and Stainless-Steel Box Kit
Adds stainless-steel side panels and painted end panels
HX-0122 – 250°F Steam
Increases outlet temperature to 250°F while lowering system pressure; adds re-sized 25° nozzle to be used as steam nozzle
HX-0124 – Auto Start/Stop and First Remote, Plastic Control Box
When trigger gun is released, the timer will turn unit off; when trigger gun is pulled, unit will restart; adds plastic control box with rocker switches, can be mounted away from unit to control on/off, burner and soap injection
HX-0217 – Elevated Float Tank, 5.0-GPM
Float tank is located at the back of the unit
HX-0218 – (2) 10-Gallon Fuel Tanks
Adds 20-gallon fuel capacity to units versus hose hook-up to fuel supply; requires HX-0216 or HX-0217 option
HX-0223 – Time Delay Shutdown and First Remote, Plastic Control Box
Timer will shut unit off automatically when trigger gun is released and timer reaches setting; adds plastic control box with rocker switches, can be mounted away from unit to control on/off, burner and soap injection
HX-0288 – (1) Remote Station (Auto Start/Stop Not Available), Metal Control Box
Adds metal control box with push-buttons, can be mounted away from unit to control on/off, burner and soap injection
HX-0289 – Time Delay Shutdown and First Remote, Metal Control Box
Timer will shut unit off automatically when trigger gun is released and timer reaches setting; adds metal control box with push-buttons, can be mounted away from unit to control on/off, burner and soap injection
HX-0290 – Additional Remotes (Up to 3)
Additional metal control boxes with push-buttons, can be added to unit after the first remote is installed; requires HX-0288 or HX-0289 option
