HEG High Volume Wash Series Stationary Natural Gas/LP Belt Drive

Name: HEG High Volume Wash Series Stationary Natural Gas/LP Belt Drive
SKU: HEG-3008-1E4G
Availability: InStock

HEG-3008-1E4G

The HEG High Volume Series can handle jobs that require maximum cleaning power. This series has a unique coil design that keeps the unit temperature steady.

Pump:
·Factory preset unloader

Motor:
·Open drip-proof electric motor with manual thermal overload protection

Frame:
·Powder coated steel frame with removable side panels

Components:
·1/2-inch schedule 80 pipe coil with 8-pancake heat exchanger
·Natural gas or LP gas-fired (vapor only) natural draft with aspirating-type burner, 12-inch stack
·Electronic ignition with intermittent pilot
·Adjustable outlet thermostat for main temperature control
·Polyethylene float tank (8-gallon with in-line screen filter)
·Time delay shutdown
·Hour meter

Miscellaneous:
·Unique coil design allows thermostat to sense upstream water temperature to regulate outlet temperatures preventing large temperature swings
·Temperature rise 150°F/66°C above ambient, maximum outlet temperature is 200°F

Unit Includes:
·Quick connect nozzles – 0°, 15°, 25°, 40° and fixed detergent nozzle
·50-foot x 3/8-inch steel wire-braided high pressure hose
·Adjustable pressure insulated dual lance
·Professional-grade insulated trigger gun with safety lock-off

Limited Warranty:
·1 year electric motor

Certification:
·ETL Certified – US and Canada

Weight	1207 lbs
Dimensions	70 × 34.75 × 54.5 in
Grade	Industrial
Water Temperature	Hot Water
Drive Type	Belt Drive
PSI	3000
GPM	7.8
Horsepower/Motor	15.0 HP, 460V, 3Ø, 19.2A
Pump	General
Natural Gas BTU per hour	650,000
LP Gas BTU Per Hour	619,500

Weight & Dimensions

Width	34.75
Height	54.5
Length	70
Shipping Weight	1207
Net Weight	1057

Product Sheet

Product Manual

Options

HX-0110 – Additional Remotes (Up to 3)
Additional plastic control boxes with rocker switches, can be added to unit after the first remote is installed; requires HX-0182 option

HX-0180 – Liquid Propane (Vapor Only)
Converts natural gas heater module to operate on liquid propane (vapor only)

HX-0181 – Auto Start/Stop
When trigger gun is released, the timer will turn unit off; when trigger gun is pulled, unit will restart

HX-0182 – (1) Remote Station
Adds plastic control box with rocker switches, can be mounted away from unit to control on/off, burner and soap injection

HX-0187 – Stainless Steel Access Panels
Converts powder coated painted access panels to stainless-steel material

HX-0188 – Stainless-Steel Coil Wrap
Converts powder coated painted coil wrap to stainless-steel material

HX-0267 – Balanced Temperature Control
Thermostat in heating coil anticipates spiking temperature and cycles the burner to maintain steady outlet temperatures

HX-0269 – Dual Gun
Two guns may be sprayed at the same time, flow is divided between the two guns while each operator maintains equal system pressure; includes HX-0267, balanced temperature control option

HX-0290 – Additional Remotes (Up to 3)
Additional metal control boxes with push-buttons, can be added to unit after the first remote is installed; requires HX-0291 option

HX-0291 – (1) Remote Station
Adds metal control box with push-buttons, can be mounted away from unit to control on/off, burner and soap injection
