HX-0104 – K7 Unloader, Flow Activated (Auto Start/Stop Not Available)
Converts pressure trapping unloader system to flow actuated K7 unloader
HX-0105 – Liquid Propane (Vapor Only)
Converts natural gas heater module to operate on liquid propane (vapor only)
HX-0106 – Hour Meter
Displays the number of hours unit has been in operation
HX-0107 – Time Delay Shutdown
Timer will shut unit off automatically when trigger gun is released and timer reaches setting (You cannot order HX-0107 and HX-0288 together, you will need to order HX-0289 instead. HX-0107 and HX-0288 can be ordered separately.)
HX-0108 – (1) Remote Station (Auto Start/Stop Not Available), Plastic Control Box
Adds plastic control box with rocker switches, can be mounted away from unit to control on/off, burner and soap injection
HX-0109 – Time Delay Shutdown and First Remote, Plastic Control Box
Timer will shut unit off automatically when trigger gun is released and timer reaches setting; adds plastic control box with rocker switches, can be mounted away from unit to control on/off, burner and soap injection
HX-0110 – Additional Remotes (Up to 3)
Additional plastic control boxes with rocker switches, can be added to unit after the first remote is installed; requires HX-0108, HX-0109 or HX-0124 option
HX-0111 – Auto Start/Stop
When trigger gun is released, the timer will turn unit off; when trigger gun is pulled, unit will restart
HX-0115 – Stainless-Steel Access Panels
Converts powder coated painted access panels to stainless-steel material
HX-0116 – Stainless-Steel Coil Wrap
Converts powder coated painted coil wrap to stainless-steel material
HX-0117 – Painted Box Kit
Adds painted side and end panels
HX-0118 – Painted and Stainless-Steel Box Kit
Adds stainless-steel side panels and painted end panels
HX-0121 – 250°F Steam
Increases outlet temperature to 250°F while lowering system pressure; adds re-sized 25° nozzle to be used as steam nozzle
HX-0124 – Auto Start/Stop and First Remote, Plastic Control Box
When trigger gun is released, the timer will turn unit off; when trigger gun is pulled, unit will restart; adds plastic control box with rocker switches, can be mounted away from unit to control on/off, burner and soap injection
HX-0154 – All Stainless-Steel Frame and Hardware on Modular Units
Converts powder coated painted frame and hardware to stainless-steel material
HX-0216 – Elevated Float Tank, 4.0-GPM
Float tank is located at the back of the unit
HX-0288 – (1) Remote Station (Auto Start/Stop Not Available), Metal Control Box
Adds metal control box with push-buttons, can be mounted away from unit to control on/off, burner and soap injection (You cannot order HX-0107 and HX-0288 together, you will need to order HX-0289 instead. HX-0107 and HX-0288 can be ordered separately.)
HX-0289 – Time Delay Shutdown and First Remote, Metal Control Box
Timer will shut unit off automatically when trigger gun is released and timer reaches setting; adds metal control box with push-buttons, can be mounted away from unit to control on/off, burner and soap injection
HX-0290 – Additional Remotes (Up to 3)
Additional metal control boxes with push-buttons, can be added to unit after the first remote is installed
HX-0296 – Programmable Logic Controller (PLC)
Includes auto start/stop and timed lockout
HX-0297 – Programmable Logic Controller with First Remote, Plastic Control Box
Includes auto start/stop and timed lockout
HX-0299 – Auto Start/Stop and First Remote, Metal Control Box
When trigger gun is released, the timer will turn unit off; when trigger gun is pulled, unit will restart; adds metal control box with push-buttons, can be mounted away from unit to control on/off, burner and soap injection
HX-0304 – Programmable Logic Controller with First Remote, Metal Control Box
Includes auto start/stop and timed lockout
HX-0305 – Additional Programmable Logic Controller Remotes, Plastic Control Box
Adds additional remotes to PLC
HX-0306 – Additional Programmable Logic Controller Remotes, Metal Control Box
Adds additional remotes to PLC
